6.00″ Thin Flange (0.400″) – Bore (4.300″)

6.00″ Thin Flange (0.400″) – Bore (4.300″)

$300.00

See specifications below.



Model #: MCF600-ThnFlg-F2-400-ID4300GG
Part #: 53-641300 Categories: ,

Description

6.00″CF 0.400″ thick – ID 4.300″
Can be used as a spacer in a UHV system
Double density clear bolt holes
Provides an easy method for inserting a phosphor screen or similar detector in front of a vacuum window
Imports the Groove Grabber technology in a UHV system
Made from 316L stainless steel
Weight: 1.06 lb. (0.48 kg)

Additional information

Weight 1.057 lbs
