Description
Focusable Electron Beams, High Current Option up to 50 mA
100 eV to 10 keV
Applications:
- Neutral Beam Excitation
- Space Physics Studies
- Surface Heating
- Surface Excitation
- Fluorescence Experiments
- Spacecraft Testing
- Vacuum Physics Experiments
Features / Options:
- Beam Currents to 50 mA
- Focusing, Deflection and Rastering
- 75” inch CF Mounting
- Computer / Remote Control
Energy Range: 100 eV to 10 keV
Beam Current / Spot Size:
Standard: 1µA to 10 mA / Standard: 1.5 mm to 20 mm
High Current: 5 mA to 50 mA / High Current:
5 mm to 25 mm
Mounting: 2.75″ CF
The Kimball Physics EGG-3103 Electron Gun, with its matching EGPS-3103 Power Supply is a medium energy, high current electron gun with applications in general vacuum physics, surface heating, excitation, ionization, fluorescence experiments, and spacecraft testing. It is a complete subsystem ready to attach and turn on.
The gun generally uses an Yttria (Y2O3) cathode to generate a high current, focusable electron beam. The gun has a Pierce style geometry with a shaped grid element and a shaped first anode element to control the beam. Both beam energy and beam current are independently adjustable over wide ranges. The energy is variable from 100 eV to 10 keV, and current from 200 μA to 10 mA. A high current option provides beam currents up to 50 mA.
To download this PDF and other associated documents, Please visit Resources Tab above.
