2.75″ Close Coupler (1.4″ length)

2.75″ Close Coupler (1.4″ length)

$625.00

See specifications below.

5 in stock



Part #: 53-520200 Categories: , ,
Model #: MCF275-ClsCplr-C2-1400

Description

Joins two 2.75″CF tapped hole components with minimal length
Bolt Type: 12-point-head 1/4-28 x 7/8 standard bolts
Incorporates one triplet of Grabber Grooves per sealing surface
1.4″ length (Gasket Plane to Gasket Plane Length: 1.380” inch (35.05 mm))
Unitary 316L stainless steel construction
Weight: 0.74 lbs. (0.33 kg)

Additional information

Weight 0.736 lbs
