8.00″ Groove Grabber – Split Axial Clamping

8.00″ Groove Grabber – Split Axial Clamping


See specifications below.

Out of stock

Part #: 53-780000 Categories: , ,
Model #: MCF800-GrvGrb-C01


-Attaches to Grabber Grooves in 8.00″ CF ports in Kimball Physics vacuum chambers & fittings
-Split design for clamping (5) 0.125″ rods or tubes parallel to port axis
(4) 4-40 tapped holes (4 screws included) for mounting “C” Series eV plates & brackets parallel to port axis
-Please go to eV Parts section of the website  to see various options for mounting devices and hardware on the Groove Grabber clamps
-All screws are gold plated for lubrication
-Weight: 0.02 lbs. (0.01 kg)

Additional information

Weight 0.024 lbs
